Amphenol Miniature Cylindrical connectors offer twice the number of contacts in just half size of a Standard connector. These miniature connectors, are available in several series, each with varying design characteristics and customer options to meet cost considerations and provide maximum design flexibility. There are two styles within the family that are MS approved and qualified to MIL-DTL-26482, Series 1, and in addition there are severla proprietary styles. Common features of all styles:

Durability: 500 cycles (Fullmating -unmating)

Operating Temperature: -55°C / +125°C

Salt Spray Exposure: > 48h

Sealing: Air leakage < 16 cm³per hour under 2 bar of differential pressure (For Solder and PCB Versions)

Hermeticity: Leak ≤ 10 cm³ .s under 1 bar differential pressure (For Hermetic Version)
