MATEC Electronics represents Amphenol Times Microwave, Amphenol TFC and Amphenol RF all together the world’s one of the famous cable manufacturer in the market of military, defence, aerospace, industrial and telecom, mobile network fields, utilizing the most advanced design and manufacturing technology along with the expertise of the experience.
RG Cables
LMR Cables
Miltech Cables
Silverline Test Cables
Hybrid Power & Fiber Cables
Heli-Foil
LLSB
LSRG
LSSB
Maxgain
NAVSEA
PhaseTrack
SFT
TCOM
Tflex
T-LNC
Waterblocked Triaxial Cables
RG Cables
M17/RG Features & Benefits
• Meets all MIL-C-17 Requirements
• Good Shielding Effectiveness
• Low Passive Intermod (PIM)
• Readily available in Distribution
• Uses Standard Connectors
M17/RG’s are traditional MIL Spec coax cables that were born 50-60 years ago. Originally created to support WWII military applications, these cables quickly became the products of choice for ommercial wireless applications once they hit the surplus market, and continue to be used today. M17/RG’s have been widely adopted for commercial and military applications. Their QPL stature insures a high quality product made to the same spec regardless of the manufacturer.
LMR Cables
Flexible Low Loss Communications Coax Ideal for
• Drop-in Replacement for specific RG cables (uses standard connectors)
• Jumper Assemblies in Wireless Communications Systems
• Short Antenna Feeder runs
• Any application (e.g. WLL, GPS, LMR, WLAN, WISP, WiMax,SCADA, Mobile Antennas) requiring an easily routed,low loss RF cable
Miltech Cables
This is our high performance workhorse series in the MilTech™ product line. These rugged, low insertion loss, broadband (0.5-18GHz), vapor sealed, cable assemblies with braided Nomex™ outer ackets for abrasion resistance, are qualified to MIL-T-81490 and MIL-C-87104/2 requirements. Cable sizes from 0.13” dia up to 0.65” diameter provide a wide range of cables - allowing you make the appropriate loss/size/weight trade-off. Replaceable connectors allow field maintenance, and enhanced versatility. Vapor sealed cables provide long life in extreme environments. The MilTech™ cables are "inherently ruggedized,” and are engineered using the basic cable design and construction to enhance the handling characteristics of the finished assemblies. Captivated contact terminations provide long-term interface stability. These assemblies were designed from the ground up to provide reliable microwave connections you can count on.
Silverline Test Cables
SilverLine™ Test Cables are cost effective, durable, highperformance cable assemblies designed for use in a broad range of test and interconnect applications. Fabricated from rugged, solid PTFE dielectric cable with stainless steel connectors and a proven strain relief system, these cables provide long life and excellent stability in applications where they are repeatedly flexed and mated/unmated. SilverLine™ test cables are ideal for use in production, field and laboratory test environments. They re also economical enough to be used as interconnects in test systems.
Features and Benefits:
• Phase & Loss Stable
• Long Flex Life
• Triple Shielded Cable
• High Mating Cycle, Stainless Steel Connectors
• Rugged, Solder/Solder Attachment
• Redundant, Long Life Strain Relief System
Silverline Cable Types:
• BronzeLine Test Cables
• SilverLine-LP Low PIM Test Cables
• SilverLine-VNA Network Analyzer Test Cables
• SilverLine-SF Super Flexible Test Cables
• SilverLine-XF Extra Flexible Test Cables
• SilverLine-LL Low Loss Test Cables
• SilverLine-TT Temperature Testing Test Cables
• SilverLine-75 75 Ohm Test Cables
• SilverLine-DAS Low PIM DAS & Component Test Cables
• SilverLine-LPA Low PIM DIN, Mini-DIN and Type N Test Adapters
Hybrid Power & Fiber Cables
Power + Optical Support Next-Generation Wireless Whether you are installing new or upgrading with wireless remote radio heads (RRHs), you need to reduce installation costs, boost performance to support 4G broadband, and ensure long-term reliability in a scalable solution to futureproof your investment. Hybrid cables from Times Fiber simplify tower cabling by providing power and optical connectivity in a single cable.
• Flexible Configurations. Get the right mix of power and optical for your tower
• High Performance. Support the latest 4G protocols, such as LTE
• Economical. Lower installation costs by running one cable instead of multiple cables
• Rugged. Tough, sunlight-resistant PVC jacket
• Lightweight. Significantly lighter than designs using corrugated metal shielding, our cables allow easier installation and less tower loading
• Complete. Install faster with factory-terminated assemblies built to your specifications
• Customizable. Specify other configurations of conductor counts, cable types, or shielding— with fast-turn delivery
LLSB
Low Loss Military/Shipboard Coax MIL-C-17 Qualified
• Low Loss Air Frame, Shipboard,
• Ground (Tactical) Interconnect
• Fire Retardant / Low Smoke (non-halogen)
• Flexible For Easy Deployment / Routing
Features & Benefits
• Lower Loss
• Superior Shielding Effectiveness
• Fire Retardant (non-halogen)
• Light Weight
• Flexible for Ease of Deployment
• Excellent Connector Selection
LSRG
LSRG Military Shipboard Coax MIL-C-17 Qualified
• MIL-Spec Air Frame, Shipboard, Ground (Tactical) Interconnect (M17/180–/200)
• Fire Retardant / Low Smoke (non-halogen)
• Flexible For Easy Deployment / Routing Features & Benefits
• Rugged Abrasion Resistant Jacket
• Excellent Shielding Effectiveness
• Fire Retardant (non-halogen)
• Light Weight
• Flexible for Ease of Deployment
• Excellent Connector Selection
LSSB
Low Smoke - Non-Halogen Military/Aerospace Coax MIL-Spec Air Frame, Shipboard, Ground (Tacti¬cal)
Features & Benefits
• Rugged Abrasion Resistant Jacket
• Excellent Shielding Effectiveness
• Fire Retardant (non-halogen)
• Light Weight
• Flexible for Ease of Deployment
• Excellent Connector Selection
NAVSEA
Amphenol Times Microwave Systems has also been approved by NAVSEA for a wide range of low-smoke designs specified for shipboard use.
PhaseTrack
Amphenol Times Microwave TF4 dielectric material is the key ingredient, making our PhaseTrack products the best choice for phase critical interconnect applications. PhaseTrack cable dielectric has been developed to eliminate the "PTFE knee” in the phase/temperature performance of cables for phase-critical applications. The PhaseTrack flexible cable product line is available in a range of sizes using TF4 dielectric.
TCOM
For applications that require repeated flexing and the need for excellent electrical performance, the TCOM-LS series offers a non-halogen, low smoke alternative to the more rigid MIL-C-28830 corrugated copper designs.
Tflex
Flexible Alternative to Semirigid Coax for Military and Commercial Applications including, Low Loss Microwave and Wireless Base Station Interconnects. Developed over ten years ago as a lighter weight, flexible alternative to semirigid coax, TFlex® has been widely adopted for both military and commercial communication systems. Its Teflon FEP jacket provides excellent protection in corrosive environments and its flexible nature eliminates the need for hand or precision machine bending. Following the most convenient routing, TFlex® can be preterminated to its desired length and can then be just "plugged in”.
Features & Benefits:
• Meets all MIL-C-17 Requirements
• Excellent Shielding Effectiveness
• Low Passive Intermod (PIM)
• Stable Loss, Phase and VSWR vs. Flexing
• Uses Standard Solder-on Semirigid Connectors
T-LNC
50 and 75 Ohm Low Noise High Performance Cables
• Stable low noise performance
• Reduced mechanically induced electrical noise
• Stranded center conductor for flexibility
• Semi-conductive layering technology
• Ruggedized polyurethane or PVC jacket
• 80° C rated
T-LNC-300-50-PUR
T-LNC-240-75-PVC
Vibration monitoring and wear detection for:
- Aerospace
- Oil & Gas
- Transportation
- Public Utility
- Machinery
- Non-Destructive Testing
Applications:
- Accelerometers
- Strain gages
- Transducers
- Low voltage signaling in high vibration
Waterblocked Triaxial Cables
For applications that require watertightness in addition to the performance requirements of the LS/LT designs, Times is qualified to the M17/134 and M17/135 designs. These triaxial designs meet the 25 psi-6 hour watertightness test, as well as the 1000 psi-2 hour hydrostatic tests that are requirements of MIL-C-17.
