MS3106A10SL-4S

MIL-C-5015 series connectors offer threaded coupled connectors with solder or crimp contacts, for general duty and harshest environment applications. Available in a variety of styles and classes, these connectors are primarily used in a range of military and industrial applications where specific degrees of environmental and EMI protections are required.
Category
Brand
QPL
Stock Code
MS3106A10SL4S
Stock Amount
25 Pcs
ORDER NOW
Please share your contact details as below. Our Sales team will get in contact with you immediately after you fill in the form in order to assist you with the ordering procedure.
*
*
*
*
Connector Series : MIL-DTL-5015
Connector Shell Style : Straight Plug
Connector Mounting Type : Cable Mount
Connector Mating Style : Threaded
Shell Material : Aluminum
Shell Plating : Olive Drab Cadmium
Shell Size and Insert Arrangement : 10SL-4
Number of Contacts and Contact Size : 2 X 16 AWG
Contact Termination Type : Solder
Contact Gender : Socket
Operating Temperature : -55°C // +125°C
Keying Rotation : N
Mating Cycle : 500
RoHS : NO
Weight : -
IP Class : -
Connector Series
MS 5015 Series
Connector Shell Style
Plug
Connector Mounting Type
Cable Mount
Connector Mating Style
Threaded
Shell Material
Aluminium
Shell Plating
Olive Drab Cadmium
Shell Size and Insert Arrangement
10SL-4
Number of Contacts and Contact AWG
2*16AWG
Contact Termination Type
Solder
Contact Gender
Socket
Operating Temperature
-55°C / +125°C
Keying Rotation
N
Mating Cycle
500
RoHS
No
