RH5MA0085M01D601A100
Temposonics® R-Series position sensors feature the highest performance, accuracy and reliability in magnetostrictive linear position technology and are designed for advanced motion control implementations in industrial applications.
ORDER NOW
Please share your contact details as below. Our Sales team will get in contact with you immediately after you fill in the form in order to assist you with the ordering procedure.
| Output signal | : | Analog |
| Connection type | : | M16 male connector (6 pin) |
| Stroke length | : | 85 mm |
| Number of magnets | : | 1 magnet |
| Output | : | Current |
| Output range | : | 0...10 VDC / 4...20 mA |
| Power consumption | : | 3.25 W |
| Operating temperature | : | -40°C // +85°C |
| Ingress protection | : | IP67 (connectors correctly fitted)/IP68 for cable outlet |
